14
Surface grinder (1,000 × 400 mm)
Surface grinding of larger flat parts, tooling and die components.
| Type | Grinding machine |
|---|---|
| Bed size | 1,000 × 400 mm |
| Stone size | Ø 360 × 50 mm thick |
| Use | Upper surface grinding |
| Quantity | 1 |
Machining
Surface grinding
Two surface grinders finish flat faces on tooling, dies and components — supporting the press and perforation tools used across the plant.
Equipment
A larger grinder with a 1,000 × 400 mm bed and Ø 360 × 50 mm stone, and a smaller grinder with a 350 × 150 mm bed and Ø 200 × 15 mm stone. Both are listed for upper surface grinding.
Equipment for this process
15
Surface grinder (350 × 150 mm)
Surface grinding of small parts and tool inserts.
| Type | Grinding machine |
|---|---|
| Bed size | 350 × 150 mm |
| Stone size | Ø 200 × 15 mm thick |
| Use | Upper surface grinding |
| Quantity | 1 |
Suitable applications
- Die and punch maintenance
- Flat ground plates and inserts
- Fixture components
Technical inputs we need from you
- Drawing with flatness and finish requirements
- Material and hardness
- Quantity
Limits and confirmations
- Part size is limited by the bed sizes listed.
- Flatness and finish values are confirmed per drawing.
How to enquire
Use the request-for-quotation form to upload drawings and specifications, or email sales.jasscosteel@gmail.com. Our team reviews feasibility and comes back with questions or a quotation.
Frequently asked questions
What size of part can you surface grind?
Parts that fit the 1,000 × 400 mm bed of the larger grinder, or the 350 × 150 mm bed of the smaller one.
